ACCELERATED GSTREAMER USER GUIDE

This document is a user guide for the Gstreamer version 1.0 based accelerated solution

included in NVIDIA

Tegra

Linux Driver Package for NVIDIA

Jetson AGX Xavier

™

devices.

Note

References to Gstreamer version 1.0 apply to Gstreamer version

1.14.

GSTREAMER-1.0 INSTALLATION AND SETUP

This section describes how to install and configure Gstreamer.

To install Gstreamer-1.0

 Install Gstreamer-1.0 on the platform with the following commands:

sudo add-apt-repository universe

sudo add-apt-repository multiverse

sudo apt-get update

sudo apt-get install gstreamer1.0-tools gstreamer1.0-alsa \

gstreamer1.0-plugins-base gstreamer1.0-plugins-good \

gstreamer1.0-plugins-bad gstreamer1.0-plugins-ugly \

gstreamer1.0-libav

sudo apt-get install libgstreamer1.0-dev \

libgstreamer-plugins-base1.0-dev \

libgstreamer-plugins-good1.0-dev \

libgstreamer-plugins-bad1.0-dev

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 2

To check the Gstreamer-1.0 version

 Check the Gstreamer-1.0 version with the following command:

gst-inspect-1.0 --version

Gstreamer-1.0 Plugin Reference

Gstreamer version 1.0 includes the following gst-omx video decoders:

Video Decoder Description

omxh265dec OpenMAX IL H.265 Video decoder

omxh264dec OpenMAX IL H.264 Video decoder

omxmpeg4videodec OpenMAX IL MPEG4 Video decoder

omxvp8dec OpenMAX IL VP8 Video decoder

omxvp9dec OpenMAX IL VP9 video decoder

Gstreamer version 1.0 includes the following gst-v4l2 video decoders:

Video Encoders

Description

nvv4l2decoder

V4L2 H.265 Video decoder

V4L2 H.264 Video decoder

V4L2 VP8 video decoder

V4L2 VP9 video decoder

Gstreamer version 1.0 includes the following gst-omx video encoders:

Video Encoders

Description

omxh264enc OpenMAX IL H.264/AVC video encoder

omxh265enc OpenMAX IL H.265/AVC video encoder

omxvp9enc

OpenMAX IL VP9 video encoder (supported with Jetson TX2

and Jetson AGX Xavier; not supported with Jetson TX1)

Gstreamer version 1.0 includes the following gst-v4l2 video encoders:

Video Encoders

Description

nvv4l2h264enc V4l2 H.264 video encoder

nvv4l2h265enc V4l2 H.265 video encoder

nvv4l2vp9enc

V4l2 VP9 video encoder (supported with Jetson AGX Xavier and

Jetson; not supported with Jetson TX1)

Gstreamer version 1.0 includes the following gst-omx video sink:

Video Sink

Description

nvoverlaysink OpenMAX IL videosink element

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 3

Gstreamer version 1.0 includes the following EGL image video sink:

Video Sink Description

nveglglessink

EGL/GLES videosink element, both the X11 and

Wayland backends

Gstreamer version 1.0 includes the following DRM video sink:

Video Sink

Description

nvdrmvideosink DRM videosink element

Gstreamer version 1.0 includes the following proprietary NVIDIA plugins:

NVIDIA Proprietary Plugin

Description

nvarguscamerasrc Camera plugin for ARGUS API

nvvidconv Video format conversion & scaling

nvcompositor Video compositor

nveglstreamsrc

Acts as Gstreamer Source Component, accepts

EGLStream from EGLStream producer

nvvideosink

Video Sink Component. Accepts YUV-I420 format and

produces EGLStream (RGBA)

nvegltransform

Video transform element for NVMM to EGLimage

(supported with nveglglessink only)

Gstreamer version 1.0 includes the following libjpeg based JPEG image video

encode/decode plugins:

JPEG

Description

nvjpegenc JPEG encoder element

nvjpegdec JPEG decoder element

Note

Execute this command on the target before starting the video

decode pipeline using gst-launch or nvgstplayer.

export DISPLAY=:0

Start the X server with xinit &, if it is not already running.

DECODE EXAMPLES

The examples in this section show how you can perform audio and video decode with

Gstreamer.

Note

Gstreamer version 0.10 support is deprecated in Linux for Tegra

(L4T) Release 24.2. Use of Gstreamer version 1.0 is recommended

for development.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 4

Audio Decode Examples Using gst-launch-1.0

The following examples show how you can perform audio decode using Gstreamer-1.0.

AAC Decode (OSS Software Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.audio_0 ! \

queue ! avdec_aac ! audioconvert ! alsasink -e

AMR-WB Decode (OSS Software Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.audio_0 ! queue ! avdec_amrwb ! \

audioconvert ! alsasink -e

AMR-NB Decode (OSS Software Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.audio_0 ! queue ! avdec_amrnb ! \

audioconvert ! alsasink -e

MP3 Decode (OSS Software Decode)

gst-launch-1.0 filesrc location=<filename.mp3> ! mpegaudioparse ! \

avdec_mp3 ! audioconvert ! alsasink -e

Note

To route audio over HDMI, set the alsasink property device as

follows:

hw:Tegra,3

Video Decode Examples Using gst-launch-1.0

The following examples show how you can perform video decode on Gstreamer-1.0.

Video Decode Using gst-omx

The following examples show how you can perform video decode using the gst-omx

plugin on Gstreamer-1.0.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 5

H.264 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h264parse ! omxh264dec ! \

nveglglessink -e

H.265 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h265parse ! omxh265dec ! \

nvoverlaysink -e

10-bit H.265 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename_10bit.mkv> ! \

matroskademux ! h265parse ! omxh265dec ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)NV12' ! \

nvoverlaysink -e

12-bit H.265 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename_12bit.mkv> ! \

matroskademux ! h265parse ! omxh265dec ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)NV12' ! \

nvoverlaysink -e

VP8 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! omxvp8dec ! \

nvoverlaysink -e

Note

If the primary display is NOT used to render video, use the display-

id property of nvoverlaysink.

For example, refer to the pipeline below.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 6

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! omxvp8dec ! \

nvoverlaysink display-id=1 -e

VP9 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

matroskademux name=demux demux.video_0 ! queue ! omxvp9dec ! \

nvoverlaysink display-id=1 -e

MPEG-4 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! mpeg4videoparse ! \

omxmpeg4videodec ! nveglglessink -e

Video Decode Using gst-v4l2

The following examples show how you can perform video decode using gst-v4l2 plugin

on Gstreamer-1.0.

H.264 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename_h264.mp4> ! \

qtdemux ! h264parse ! nvv4l2decoder ! nvoverlaysink -e

H.265 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename_h265.mp4> ! \

qtdemux ! h265parse ! nvv4l2decoder ! nvoverlaysink -e

VP9 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename_vp9.mkv> ! \

matroskademux ! nvv4l2decoder ! nvoverlaysink -e

VP8 Decode (NVIDIA Accelerated Decode)

gst-launch-1.0 filesrc location=<filename_vp8.mkv> ! \

matroskademux ! nvv4l2decoder ! nvoverlaysink -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 7

Image Decode Examples Using gst-launch-1.0

The following examples show how you can perform JPEG decode on Gstreamer-1.0 .

gst-launch-1.0 filesrc location=<filename.jpg> ! nvjpegdec ! \

imagefreeze ! xvimagesink -e

ENCODE EXAMPLES

The examples in this section show how you can perform audio and video encode with

Gstreamer.

Audio Encode Examples Using gst-launch-1.0

The following examples show how you can perform audio encode on Gstreamer-1.0.

AAC Encode (OSS Software Encode)

gst-launch-1.0 audiotestsrc ! \

'audio/x-raw, format=(string)S16LE,

layout=(string)interleaved, rate=(int)44100, channels=(int)2' ! \

voaacenc ! qtmux ! filesink location=test.mp4 -e

AMR-WB Encode (OSS Software Encode)

gst-launch-1.0 audiotestsrc ! \

'audio/x-raw, format=(string)S16LE, layout=(string)interleaved, \

rate=(int)16000, channels=(int)1' ! voamrwbenc ! qtmux ! \

filesink location=test.mp4 -e

Video Encode Examples Using gst-launch-1.0

The following examples show how you can perform video encode with Gstreamer-1.0.

Video Encode Using gst-omx

The following examples show how you can perform video encode using the gst-omx

plugin with Gstreamer-1.0.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 8

H.264 Encode (NVIDIA Accelerated Encode)

gst-launch-1.0 videotestsrc ! \

'video/x-raw, format=(string)I420, width=(int)640, \

height=(int)480' ! omxh264enc ! \

'video/x-h264, stream-format=(string)byte-stream' ! h264parse ! \

qtmux ! filesink location=test.mp4 -e

H.265 Encode (NVIDIA Accelerated Encode)

gst-launch-1.0 videotestsrc ! \

'video/x-raw, format=(string)I420, width=(int)640, \

height=(int)480' ! omxh265enc ! filesink location=test.h265 -e

10-bit H.265 Encode (NVIDIA Accelerated Encode)

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! \

nvvidconv ! 'video/x-raw(memory:NVMM), format=(string)I420_10LE' !

omxh265enc ! matroskamux ! filesink location=test_10bit.mkv -e

VP9 Encode (NVIDIA Accelerated, Supported with Jetson TX2 and Jetson

AGX Xavier)

gst-launch-1.0 videotestsrc ! \

'video/x-raw, format=(string)I420, width=(int)640, \

height=(int)480' ! omxvp9enc ! matroskamux ! \

filesink location=test.mkv -e

MPEG-4 Encode (OSS Software Encode)

gst-launch-1.0 videotestsrc ! \

'video/x-raw, format=(string)I420, width=(int)640, \

height=(int)480' ! avenc_mpeg4 ! qtmux ! \

filesink location=test.mp4 -e

H.263 Encode (OSS Software Encode)

gst-launch-1.0 videotestsrc ! \

'video/x-raw, format=(string)I420, width=(int)704, \

height=(int)576' ! avenc_h263 ! qtmux ! filesink location=test.mp4 -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 9

Video Encode Using gst-v4l2

The following examples show how you can perform video encode using gst-v4l2 plugin

with Gstreamer-1.0.

H.264 Encode (NVIDIA Accelerated Encode)

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! nvv4l2h264enc ! \

h264parse ! qtmux ! filesink location=<filename_h264.mp4> -e

H.265 Encode (NVIDIA Accelerated Encode)

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! nvv4l2h265enc ! \

h265parse ! qtmux ! filesink location=<filename_h265.mp4> -e

VP9 Encode (NVIDIA Accelerated Encode)

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! nvv4l2vp9enc ! \

matroskamux ! filesink location=<filename_vp9.mkv> -e

VP9 Encode with IVF Headers (NVIDIA Accelerated Encode)

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! nvv4l2vp9enc \

enable-headers=1 ! filesink location=<filename_vp9.vp9> -e

Image Encode Examples Using gst-launch-1.0

The following examples show how you can perform JPEG encode on Gstreamer-1.0 .

Image Encode

gst-launch-1.0 videotestsrc num-buffers=1 ! \

'video/x-raw, width=(int)640, height=(int)480, \

format=(string)I420' ! nvjpegenc ! filesink location=test.jpg -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 10

Supported H.264/H.265/VP9 Encoder Features with

Gstreamer-1.0

This section describes example gst-launch-1.0 usage for features supported by the

NVIDIA accelerated H.264/H.265 encoders.

Features Supported Using gst-omx

This section describes example gst-launch-1.0 usage for features supported by the

NVIDIA accelerated H.264/H.265 gst-omx encoders.

Note

Display detailed information on omxh264enc or omxh265enc encoder

properties with the gst-inspect-1.0 [omxh264enc |

omxh265enc] command.

Set I-Frame Interval

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc iframeinterval=100 ! qtmux ! \

filesink location=test.mp4 -e

Set Temporal-Tradeoff (Rate at Which the Encoder Should Drop Frames)

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc temporal-tradeoff=1 ! qtmux ! \

filesink location=test.mp4 -e

Configuring temporal tradeoff causes the encoder to intentionally, periodically, drop

input frames. The following modes are supported:

Mode

Description

0 Disable

1 Drop 1 in 5 frames

2 Drop 1 in 3 frames

3 Drop 1 in 2 frames

4 Drop 2 in 3 frames

Set Rate Control Mode

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc control-rate=1 ! qtmux ! \

filesink location=test.mp4 -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 11

The following modes are supported:

Mode Description

0 Disable

1 Variable bit rate

2 Constant bit rate

Variable bit rate with frame skip. The encoder skips

frames as necessary to meet the target bit rate.

4 Constant bit rate with frame skip

Set Peak Bitrate

gst-launch-1.0 videotestsrc num-buffers=200 is-live=true ! \

'video/x-raw,width=1280,height=720,format=I420' ! \

omxh264enc bitrate=6000000 peak-bitrate=6500000 ! qtmux ! \

filesink location=test.mp4 -e

It takes effect only in variable bit rate(control-rate=1) mode. By default, the value is

configured as (1.2*bitrate).

Set Quantization Range for I, P and B Frame

The format for the range is the following:

”<I_range>:<P_range>:<B_range>”

Where <I_range>, <P_range> and <B_range> are each expressed as hyphenated

values, as shown in the following example:

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! \

omxh264enc qp-range="10,30:10,35:10,35" ! qtmux ! \

filesink location=test.mp4 -e

The range of B frames does not take effect if the number of B frames is 0.

Set Hardware Preset Level

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc preset-level=0 ! qtmux ! \

filesink location=test.mp4 -e

The following modes are supported:

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 12

Mode

Description

0 UltraFastPreset

FastPreset

Only Integer Pixel (integer-pel) block motion is

estimated. For I/P macroblock mode decision, only

Intra 16 x 16 cost is compared with Inter modes costs.

Supports Intra 16 x 16 and Intra 4 x 4 modes.

MediumPreset

Supports up to Half Pixel (half-pel) block motion

estimation. For an I/P macroblock mode decision, only

Intra 16 x 16 cost is compared with Inter modes costs.

Supports Intra 16 x 16 and Intra 4 x 4 modes.

SlowPreset

Supports up to Quarter Pixel (Qpel) block motion

estimation. For an I/P macroblock mode decision, Intra

4 x 4 as well as Intra 16 x 16 cost is compared with

Inter modes costs. Supports Intra 16 x 16 and Intra 4 x

4 modes.

Set Profile

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc profile=8 ! qtmux ! \

filesink location=test.mp4 -e

From omxh264enc, the following profiles are supported:

Profile Description

1 Baseline profile

2 Main profile

8 High profile

Set Level

gst-launch-1.0 videotestsrc num-buffers=200 is-live=true ! \

'video/x-raw, format=(string)I420, width=(int)256, height=(int)256, \

framerate=(fraction)30/1' ! omxh264enc bitrate=40000 !\

'video/x-h264, level=(string)2.2' ! qtmux ! \

filesink location= test.mp4 -e

From omxh264enc, the following levels are supported: 1, 1b, 1.2, 1.3, 2, 2.1,

2.2, 3, 3.1, 3.2, 4, 4.1, 4.2, 5, 5.1, and 5.2.

From omxh265enc, the following levels are supported: main1, main2, main2.1,

main3, main3.1, main4, main4.1, main5, high1, high2, high2.1,

high3, high3.1, high4, high4.1, and high5.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 13

Set Number of B Frames Between Two Reference Frames

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc num-B-Frames=2 ! qtmux ! \

filesink location=test.mp4 -e

Note

B-frame-encoding is not supported with omxh265enc.

Insert SPS and PPS at IDR

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc insert-sps-pps=1 ! qtmux ! \

filesink location=test.mp4 -e

If enabled, a sequence parameter set (SPS) and a picture parameter set (PPS) are inserted

before each IDR frame in the H.264/H.265 stream.

Enable Two-Pass CBR

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc EnableTwopassCBR=1

control-rate=2 ! qtmux ! filesink location=test.mp4 -e

Two-pass CBR must be enabled along with constant bit rate (control-rate=2).

Set Virtual Buffer Size

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! omxh264enc vbv-size=10 ! qtmux ! \

filesink location=test.mp4 -e

If the buffer size of decoder or network bandwidth is limited, configuring virtual buffer

size can cause video stream generation to correspond to the limitations according to the

following formula:

virtual buffer size = vbv-size * (bitrate/fps)

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 14

Enable Stringent Bitrate

gst-launch-1.0 nvarguscamerasrc num-buffers=200 ! \

'video/x-raw(memory:NVMM),width=1920,height=1080,

format=(string)NV12' ! \

omxh264enc control-rate=2 vbv-size=1 EnableTwopassCBR=true \

EnableStringentBitrate=true ! qtmux ! filesink location=test.mp4 -e

Stringent Bitrate must be enabled along with constant bit rate (control-rate=2), two-pass

CBR being enabled, and virtual buffer size being set.

Slice-Header-Spacing with Spacing in Terms of MB

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! \

omxh264enc slice-header-spacing=200 bit-packetization=0 ! \

qtmux ! filesink location=test.mp4 -e

The parameter bit-packetization=0 configures the network abstraction layer

(NAL) packet as macroblock (MB)-based, and slice-header-spacing=200

configures each NAL packet as 200 MB at maximum.

Slice Header Spacing with Spacing in Terms of Number of Bits

gst-launch-1.0 videotestsrc num-buffers=200 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420' ! \

omxh264enc slice-header-spacing=1024 bit-packetization=1 ! \

qtmux ! filesink location=test1.mp4 -e

The parameter bit-packetization=1 configures the network abstraction layer

(NAL) packet as size-based, and slice-header-spacing=1024 configures each NAL

packet as 1024 bytes at maximum.

Features Supported Using gst-v4l2

This section describes example gst-launch-1.0 usage for features supported by the

NVIDIA accelerated H.264/H.265/VP9 gst-v4l2 encoders.

Note

Display detailed information on the nvv4l2h264enc, nvv4l2h265enc,

or nvv4l2vp9enc encoder property with the gst-inspect-1.0

[nvv4l2h264enc | nvv4l2h265enc | nvv4l2vp9enc]

command.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 15

Set I-Frame Interval (Supported with H.264/H.265/VP9 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

iframeinterval=100 ! h264parse ! qtmux ! filesink \

location=<filename_h264.mp4> -e

This property sets encoding Intra Frame occurrence frequency.

Set Rate Control Mode and Bitrate (Supported with H.264/H.265/VP9

Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

control-rate=0 bitrate=30000000 ! h264parse ! qtmux ! filesink \

location=<filename_h264_VBR.mp4> -e

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

control-rate=1 bitrate=30000000 ! h264parse ! qtmux ! filesink \

location=<filename_h264_CBR.mp4> -e

The following modes are supported:

Mode

Description

0 Variable bit rate (VBR)

1 Constant bit rate (CBR)

Set Quantization Range for I, P and B frame (Supported with H.264/H.265

Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

ratecontrol-enable=0 quant-i-frames=30 quant-p-frames=30 \

quant-b-frames=30 num-B-Frames=1 ! filesink \

location=<filename_h264.264> -e

The range of B frames does not take effect if the number of B frames is 0.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 16

Set Hardware Preset Level (Supported with H.264/H.265/VP9 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

preset-level=4 MeasureEncoderLatency=1 ! 'video/x-h264, \

stream-format=(string)byte-stream, alignment=(string)au' ! \

filesink location=<filename_h264.264> -e

The following modes are supported:

Mode Description

0 DisablePreset

1 UltraFastPreset

FastPreset

Only Integer Pixel (integer-pel) block motion is

estimated. For I/P macroblock mode decisions, only

Intra 16×16 cost is compared with intermode costs.

Supports intra 16×16 and intra 4×4 modes.

MediumPreset

Supports up to Half Pixel (half-pel) block motion

estimation. For I/P macroblock mode decisions, only

Intra 16×16 cost is compared with intermode costs.

Supports intra 16×16 and intra 4×4 modes.

SlowPreset

Supports up to Quarter Pixel (Qpel) block motion

estimation. For I/P macroblock mode decisions, intra

4×4 as well as intra 16×16 cost is compared with

intermode costs. Supports intra 16×16 and intra 4×4

modes.

Set Profile (Supported with H.264 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

profile=0 ! 'video/x-h264, stream-format=(string)byte-stream, \

alignment=(string)au' ! filesink location=<filename_h264.264> -e

The following profiles are supported:

Profile

Description

0 Baseline profile

2 Main profile

4 High profile

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 17

Insert SPS and PPS at IDR (Supported with H.264 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

insert-sps-pps=1 ! \

'video/x-h264, stream-format=(string)byte-stream, \

alignment=(string)au' ! filesink location=<filename_h264.264> -e

If enabled, a sequence parameter set (SPS) and a picture parameter set (PPS) are inserted

before each IDR frame in the H.264 stream.

Enable Two-Pass CBR (Supported with H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

control-rate=1 bitrate=10000000 EnableTwopassCBR=1 ! \

'video/x-h264, stream-format=(string)byte-stream, \

alignment=(string)au' ! filesink location=<filename_h264.264> -e

Two-pass CBR must be enabled along with constant bit rate (control-rate=1).

Slice-Header-Spacing with Spacing in Terms of MB (Supported with

H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

slice-header-spacing=8 bit-packetization=0 ! 'video/x-h264, \

stream-format=(string)byte-stream, alignment=(string)au' ! \

filesink location=<filename_h264.264> -e

The parameter bit-packetization=0 configures the network abstraction layer

(NAL) packet as macroblock (MB)-based, and slice-header-spacing=8 configures

each NAL packet as 8 MB at maximum.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 18

Slice Header Spacing with Spacing in Terms of Number of Bits (Supported

with H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

slice-header-spacing=1400 bit-packetization=1 ! 'video/x-h264, \

stream-format=(string)byte-stream, alignment=(string)au' ! \

filesink location=<filename_h264.264> -e

The parameter bit-packetization=1 configures the network abstraction layer

(NAL) packet as size-based, and slice-header-spacing=1400 configures each NAL

packet as 1400 bytes at maximum.

Enable Cabac-Entropy-Coding (Supported with H.264 Encode for Main or

High Profile)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

profile=2 cabac-entropy-coding=1 ! 'video/x-h264, \

stream-format=(string)byte-stream, alignment=(string)au' ! \

filesink location=<filename_h264.264> -e

The following entropy coding types are supported:

Entropy Coding Type

Description

0 CAVLC

1 CABAC

Set Number of B Frames Between Two Reference Frames (Supported with

H.264 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

num-B-Frames=1 ! 'video/x-h264, stream-format=(string)byte-stream, \

alignment=(string)au' ! filesink location=<filename_h264.264> -e

This property sets the number of B frames between two reference frames.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 19

Set qp-range (Supported with H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

qp-range="24,24:28,28:30,30" num-B-Frames=1 ! 'video/x-h264, \

stream-format=(string)byte-stream, alignment=(string)au' ! filesink \

location=<filename_h264.264> -e

This property sets qunatization range for P, I and B frames.

Enable MVBufferMeta (Supported with H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

EnableMVBufferMeta=1 ! 'video/x-h264, \

stream-format=(string)byte-stream, alignment=(string)au' ! \

filesink location=<filename_h264.264> -e

This property enables motion vector metadata for encoding.

Insert AUD (Supported with H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

insert-aud=1 ! 'video/x-h264, stream-format=(string)byte-stream, \

alignment=(string)au' ! filesink location=<filename_h264.264> -e

This property inserts an H.264/H.265 Access Unit Delimiter (AUD).

Insert VUI (Supported with H.264/H.265 Encode)

gst-launch-1.0 videotestsrc num-buffers=300 ! \

'video/x-raw, width=(int)1280, height=(int)720, \

format=(string)I420, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvv4l2h264enc \

insert-vui=1 ! 'video/x-h264, stream-format=(string)byte-stream, \

alignment=(string)au' ! filesink location=<filename_h264.264> -e

This property inserts H.264/H.265 Video Usability Information (VUI) in SPS.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 20

CAMERA CAPTURE WITH GSTREAMER-1.0

For nvgstcapture-1.0 usage information enter the following command:

nvgstcapture-1.0 --help

Note

nvgstcapture-1.0 application default only supports ARGUS API using

nvarguscamerasrc plugin. Legacy nvcamerasrc plugin support is

deprecated.

For more information, see Nvgstcapture-1.0 Option Reference in this guide.

Capture using nvarguscamerasrc and preview display with overlaysink:

gst-launch-1.0 nvarguscamerasrc ! ‘video/x-raw(memory:NVMM), \

width=1920, height=1080, format=(string)NV12, \

framerate=(fraction)30/1' ! nvoverlaysink -e

The nvgstcapture-1.0 application uses the v4l2src plugin to capture still images

and video.

The following table shows USB camera support.

USB Camera Support Feature

YUV

Preview display

Image capture (VGA, 640 x 480)

Video capture (480p, 720p, H.264/H.265/VP9 encode)

raw-yuv Capture (I420 Format) and Preview Display with xvimagesink

gst-launch-1.0 v4l2src device="/dev/video0" ! \

"video/x-raw, width=640, height=480, format=(string)I420" ! \

xvimagesink -e

VIDEO PLAYBACK WITH GSTREAMER-1.0

For nvgstplayer-1.0 usage information enter the following command:

nvgstplayer-1.0 --help

Video can be output to HD displays using the HDMI connector on the platform. The

Gstreamer-1.0 application supports currently the following video sinks:

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 21

Overlay Sink (Video playback on overlay in full-screen mode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux ! h264parse ! omxh264dec ! nvoverlaysink -e

Overlay Sink (Video playback using overlay parameters)

Note:

The following steps are required to use the “overlay” property on

Jetson-TX2.

1. Set win_mask with the following commands:

# sudo -s

# cd /sys/class/graphics/fb0

# echo 4 > blank // Blanks monitor for changing

# // display setting.

# echo 0x0 > device/win_mask

# // Clears current window setting.

# // window setting.

# echo 0x3f > device/win_mask

# // Assigns all 6 overlay windows

# // in display controller to

# // display 0 (fb0).

# echo 0 > blank // Unblank display.

2. Stop X11 using following command:

$ sudo systemctl stop gdm

$ sudo loginctl terminate-seat seat0

For more introduction about the overlay windows in the display

controller, please refer to the TX2 Technical Reference Manual

(TRM).

To use all 6 overlays X11 must be disabled, since it occupies one

window. Disabling X11 also helps avoid memory bandwidth contention

when using a non X11 overlay.

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! \

qtdemux ! h264parse ! omxh264dec \

nvoverlaysink overlay-x=100 overlay-y=100 overlay-w=640 \

overlay-h=480 overlay=1 \

overlay-depth=0 & gst-launch-1.0 filesrc \

location=<filename_1080p.mp4> ! qtdemux ! h264parse ! omxh264dec ! \

nvoverlaysink overlay-x=250 overlay-y=250 overlay-w=640 \

overlay-h=480 overlay=2 overlay-depth=1 -e

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! \

qtdemux ! h264parse ! omxh264dec \

nvoverlaysink overlay-x=100 overlay-y=100 overlay-w=640 \

overlay-h=480 overlay=1 overlay-depth=2 & gst-launch-1.0 filesrc \

location=<filename_1080p.mp4> ! qtdemux ! h264parse ! omxh264dec ! \

nvoverlaysink overlay-x=250 overlay-y=250 overlay-w=640 \

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 22

overlay-h=480 overlay=2 overlay-depth=1 -e

nveglglessink (Windowed video playback, NVIDIA EGL/GLES videosink

using default X11 backend)

Use the following command to start the Gstreamer pipeline using nveglglesink with

the default X11 backend:

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux ! h264parse ! omxh264dec ! nveglglessink -e

This nvgstplayer-1.0 application supports specific window position and dimensions for

windowed playback:

nvgstplayer-1.0 -i <filename> --window-x=300 --window-y=300 \

--window-width=500 --window-height=500

nveglglessink (Windowed video playback, NVIDIA EGL/GLES videosink

using Wayland backend)

You can also use nveglglsink with the Wayland backend, instead of the default X11

backend.

Ubuntu 16.04 does not support the Wayland display server. That is, there is no UI

support to switch to Wayland from Xorg. You must start the Wayland server (Weston)

using the target’s shell before performing any Weston based operation.

To start Weston:

The following steps are required before you first run the GStreamer pipeline with the

Wayland backend. They are not required on subsequent runs.

1. Stop the display manager:

sudo systemctl stop gdm

sudo loginctl terminate-seat seat0

2. Unset the DISPLAY environment variable:

unset DISPLAY

3. Create a temporary xdg directory:

mkdir /tmp/xdg

chmod 700 /tmp/xdg

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 23

4. Start the Weston compositor:

sudo XDG_RUNTIME_DIR=/tmp/xdg weston --idle-time=0 &

To run the GStreamer pipeline with the Wayland backend:

Use the following command to start the Gstreamer pipeline using nveglglesink with

the Wayland backend:

sudo XDG_RUNTIME_DIR=/tmp/xdg gst-launch-1.0 filesrc \

location=<filename.mp4> ! qtdemux name=demux ! h264parse ! \

omxh264dec ! nveglglessink winsys=wayland

DRM Video Sink (Video playback using DRM)

This sink element uses DRM to render video on connected displays.

Prerequisite:

1. Stop the display manager:

sudo systemctl stop gdm

sudo loginctl terminate-seat seat0

The following command starts the Gstreamer pipeline using nvdrmvideosink:

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux ! h264parse ! omxh264dec ! nvdrmvideosink -e

Properties

nvdrmvideosink supports the following properties:

Property name

Description

conn_id Set connector ID for display.

plane_id Set plane ID.

set_mode Set default mode (resolution) for playback.

The following command illustrates the use of these properties:

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux ! h264parse ! omxh264dec ! nvdrmvideosink \

conn_id=0 plane_id=1 set_mode=0 -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 24

VIDEO FORMAT CONVERSION WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plugin allows conversion between

OSS (raw) video formats and NVIDIA video formats. The nvvidconv plugin currently

supports the format conversions described in this section

raw-yuv Input Formats

Currently nvvidconv supports the I420, UYVY, YUY2, YVYU, NV12, BGRx, and RGBA

raw-yuv input formats.

gst-launch-1.0 videotestsrc ! 'video/x-raw, format=(string)UYVY, \

width=(int)1280, height=(int)720' ! nvvidconv ! \

'video/x-raw(memory:NVMM), format=(string)I420’ ! omxh264enc ! \

'video/x-h264, stream-format=(string)byte-stream' ! h264parse ! \

qtmux ! filesink location=test.mp4 -e

raw-yuv Output Formats

Currently nvvidconv supports the I420, UYVY, YUY2, YVYU, NV12, BGRx, and RGBA

raw-yuv output formats.

gst-launch-1.0 filesrc location=640x480_30p.mp4 ! qtdemux ! queue ! \

h264parse ! omxh264dec ! nvvidconv ! \

'video/x-raw, format=(string)UYVY' ! videoconvert ! xvimagesink -e

VIDEO SCALING WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plugin also allows you to perform

video scaling. The nvvidconv plugin currently supports scaling with the format

conversions described in this section.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 25

raw-yuv Input Formats

Currently nvvidconv supports the I420, UYVY, YUY2, YVYU, NV12, BGRx, and RGBA

raw-yuv input formats for scaling.

gst-launch-1.0 videotestsrc ! \

'video/x-raw, format=(string)I420, width=(int)1280, \

height=(int)720' ! nvvidconv ! \

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480, \

format=(string)I420' ! omxh264enc ! \

'video/x-h264, stream-format=(string)byte-stream' ! h264parse ! \

qtmux ! filesink location=test.mp4 -e

raw-yuv Output Formats

Currently nvvidconv supports the I420, UYVY, YUY2, YVYU, NV12, BGRx, and RGBA

raw-yuv output formats for scaling.

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! queue ! \

h264parse ! omxh264dec ! nvvidconv ! \

'video/x-raw, format=(string)I420, width=640, height=480' ! \

xvimagesink -e

NVIDIA Input and Output Formats

Currently nvvidconv supports the NVIDIA input and output formats for scaling

described in the following table:

Input Format

Output Format

NV12 NV12

I420, I420_10LE, I420_12LE I420, I420_10LE

RGBA

To scale between NVIDIA formats

 Scale between NVIDIA Formats with the following commands:

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! \

h264parse ! omxh264dec ! nvvidconv ! \

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480, \

format=(string)I420' ! omxh264enc ! qtmux ! \

filesink location=test.mp4 -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 26

gst-launch-1.0 filesrc location=1280x720_30p.mp4 ! qtdemux ! \

h264parse ! omxh264dec ! nvvidconv ! \

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480, \

format=(string)RGBA' ! nvoverlaysink -e

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! nvvidconv ! \

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480, \

format=(string)NV12’ ! omxh264enc ! \

qtmux ! filesink location=test.mp4 -e

VIDEO CROPPING WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plugin also allows you to perform

video cropping.

To crop video

 Crop video with the following commands:

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! qtdemux ! \

h264parse ! omxh264dec ! \

nvvidconv left=400 right=1520 top=200 bottom=880 ! \

nvoverlaysink display-id=1 -e

VIDEO TRANSCODE WITH GSTREAMER-1.0

You can perform video transcoding between the following video formats.

H.264 Decode to VP9 Encode (NVIDIA Accelerated Decode to NVIDIA-

Accelerated Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h264parse ! omxh264dec ! \

omxvp9enc bitrate=20000000 ! matroskamux name=mux ! \

filesink location=<Transcoded_filename.mkv> -e

H.265 Decode to VP9 Encode (NVIDIA Accelerated Decode to NVIDIA-

Accelerated Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h265parse ! omxh265dec ! \

omxvp9enc bitrate=20000000 ! matroskamux name=mux ! \

filesink location=<Transcoded_filename.mkv> -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 27

VP8 Decode to H.264 Encode (NVIDIA Accelerated Decode to NVIDIA-

Accelerated Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! omxvp8dec ! \

omxh264enc bitrate=20000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

VP9 Decode to H.265 Encode (NVIDIA Accelerated Decode to NVIDIA-

Accelerated Encode)

gst-launch-1.0 filesrc location=<filename.webm> ! \

matroskademux name=demux demux.video_0 ! queue ! omxvp9dec ! \

omxh265enc bitrate=20000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

MPEG-4 Decode to VP9 Encode (NVIDIA Accelerated Decode to NVIDIA-

Accelerated Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! mpeg4videoparse ! \

omxmpeg4videodec ! omxvp9enc bitrate=20000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

MPEG-4 Decode to H.264 Encode (NVIDIA Accelerated Decode to NVIDIA-

Accelerated Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! mpeg4videoparse ! \

omxmpeg4videodec ! omxh264enc bitrate=20000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

H.264 Decode to MPEG-4 Encode (NVIDIA Accelerated Decode to OSS

Software Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h264parse ! omxh264dec ! \

nvvidconv ! avenc_mpeg4 bitrate=4000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 28

H.265 Decode to MPEG-4 Encode (NVIDIA Accelerated Decode to OSS

Software Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h265parse ! omxh265dec ! \

nvvidconv ! avenc_mpeg4 bitrate=4000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

VP8 Decode to MPEG-4 Encode (NVIDIA Accelerated Decode to OSS

Software Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! omxvp8dec ! nvvidconv ! \

avenc_mpeg4 bitrate=4000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

VP9 Decode to MPEG-4 Encode (NVIDIA Accelerated Decode to OSS

Software Encode)

gst-launch-1.0 filesrc location=<filename.mkv> ! \

matroskademux name=demux demux.video_0 ! queue ! omxvp9dec ! \

nvvidconv ! avenc_mpeg4 bitrate=4000000 ! qtmux name=mux ! \

filesink location=<Transcoded_filename.mp4> -e

H.264 Decode to Theora Encode (NVIDIA Accelerated Decode to OSS

Software Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h264parse ! omxh264dec ! \

nvvidconv ! theoraenc bitrate=4000000 ! oggmux name=mux ! \

filesink location=<Transcoded_filename.ogg> -e

H.264 Decode to H.263 Encode (NVIDIA Accelerated Decode to OSS

Software Encode)

gst-launch-1.0 filesrc location=<filename.mp4> ! \

qtdemux name=demux demux.video_0 ! queue ! h264parse ! omxh264dec ! \

nvvidconv ! 'video/x-raw, width=(int)704, height=(int)576, \

format=(string)I420' ! avenc_h263 bitrate=4000000 ! qtmux ! \

filesink location=<Transcoded_filename.mp4> -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 29

CUDA VIDEO POST-PROCESSING WITH GSTREAMER-

1.0

This section describes Gstreamer-1.0 plugins for NVIDIA

CUDA

post-processing

operations.

gst-videocuda

This GStreamer-1.0 plugin performs CUDA post-processing operations on decoder-

provided EGL images and render video using nveglglessink.

The following are sample pipeline creation and application usage commands.

Sample decode pipeline

gst-launch-1.0 filesrc location=<filename_h264_1080p.mp4> ! \

qtdemux name=demux ! h264parse ! omxh264dec ! videocuda !\

nveglglessink max-lateness=-1 -e

Sample decode command

nvgstplayer-1.0 -i <filename_h264_1080p.mp4> --svd="omxh264dec" \

--svc="videocuda" --svs="nveglglessink # max-lateness=-1" \

--disable-vnative --no-audio --window-x=0 --window-y=0 \

--window-width=960 --window-height=540

gst-nvivafilter

This NVIDIA proprietary GStreamer-1.0 plugin performs pre/post and CUDA post-

processing operations on CSI camera captured or decoded frames, and renders video

using overlay video sink or video encode.

Sample decode pipeline

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux ! \

h264parse ! omxh264dec ! nvivafilter cuda-process=true \

customer-lib-name="libnvsample_cudaprocess.so" ! \

'video/x-raw(memory:NVMM), format=(string)NV12' ! nvoverlaysink -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 30

Sample CSI Camera pipeline

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)3840, height=(int)2160, \

format=(string)NV12, framerate=(fraction)30/1' ! \

nvivafilter cuda-process=true \

customer-lib-name="libnvsample_cudaprocess.so" ! \

'video/x-raw(memory:NVMM), format=(string)NV12' ! nvoverlaysink -e

Note

See nvsample_cudaprocess_src.tbz2 package for the

libnvsample_cudaprocess.so library sources. A Sample CUDA

implementation of libnvsample_cudaprocess.so can be replaced by a

custom CUDA implementation.

VIDEO ROTATION WITH GSTREAMER-1.0

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plugin also allows you to perform

video rotation operations.

The following table shows the supported values for the nvvidconv flip-method

property.

Flip Method

Property value

identity - no rotation (default) 0

counterclockwise - 90 degrees 1

rotate - 180 degrees 2

clockwise - 90 degrees 3

horizontal flip 4

upper right diagonal flip 5

vertical flip 6

upper-left diagonal 7

Note

Get information on nvvidconv flip-method property with the

gst-

inspect-1.0 nvvidconv

command.

To rotate video 90 degrees counterclockwise

 To rotate video 90 degrees in a counterclockwise direction, enter the following

command.

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux ! \

h264parse ! omxh264dec ! nvvidconv flip-method=1 ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvoverlaysink -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 31

To rotate video 90 degrees clockwise

 To rotate video 90 degrees in a clockwise direction, enter the following command:

gst-launch-1.0 filesrc location=<filename.mp4> ! qtdemux name=demux ! \

h264parse ! omxh264dec ! nvvidconv flip-method=3 ! \

'video/x-raw(memory:NVMM), format=(string)I420’ ! \

omxh264enc ! qtmux ! filesink location=test.mp4 -e

To rotate 180 degrees

 To rotate video 180 degrees, enter the following command:

gst-launch-1.0 nvarguscamerasrc! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! \

nvvidconv flip-method=2 ! \

'video/x-raw(memory:NVMM), format=(string)I420' ! nvoverlaysink -e

To scale and rotate video 90 degrees counterclockwise

 To scale and rotate video 90 degrees counterclockwise, enter the following

command:

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! qtdemux ! \

h264parse ! omxh264dec ! nvvidconv flip-method=1 ! \

'video/x-raw(memory:NVMM), width=(int)480, height=(int)640, \

format=(string)I420' ! nvoverlaysink -e

To scale and rotate video 90 degrees clockwise

 To scale and rotate video 90 degrees clockwise, enter the following command:

gst-launch-1.0 nvarguscamerasrc ! \

'video/x-raw(memory:NVMM), width=(int)1920, height=(int)1080, \

format=(string)NV12, framerate=(fraction)30/1' ! \

nvvidconv flip-method=3 ! 'video/x-raw(memory:NVMM), \

width=(int)480, height=(int)640, format=(string)I420' ! \

nvoverlaysink -e

To scale and rotate video 180 degrees

 To scale and rotate video 180 degrees, enter the following command:

gst-launch-1.0 filesrc location=<filename_1080p.mp4> ! \

qtdemux ! h264parse ! omxh264dec ! nvvidconv flip-method=2 ! \

'video/x-raw(memory:NVMM), width=(int)640, height=(int)480, \

format=(string)I420' ! nvoverlaysink -e

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 32

VIDEO COMPOSITION WITH GSTREAMER-1.0

With the NVIDIA proprietary nvcompositor Gstreamer-1.0 plugin, you can perform

video composition operations on gst-omx video decoded streams.

Note

nvcompositor supports video decode (gst-omx) with the overlay render

pipeline for gst-1.14.

Prerequisites

 Install the following dependent gstreamer package.

$ sudo apt-get install gstreamer1.0-plugins-bad

 Clear the registry cache file, in case there is an issue with gst-inspect-1.0

nvcompositor.

$ rm .cache/gstreamer-1.0/registry.aarch64.bin

To composite different formats decoded streams

 Enter the following command:

gst-launch-1.0 nvcompositor \

name=comp sink_0::xpos=0 sink_0::ypos=0 sink_0::width=1920 \

sink_0::height=1080 sink_1::xpos=0 sink_1::ypos=0 \

sink_1::width=1600 sink_1::height=1024 sink_2::xpos=0 \

sink_2::ypos=0 sink_2::width=1366 sink_2::height=768 \

sink_3::xpos=0 sink_3::ypos=0 sink_3::width=1024 \

sink_3::height=576 ! nvoverlaysink display-id=1 \

filesrc location=<filename_h264_1080p_30fps.mp4> ! qtdemux ! \

h264parse ! omxh264dec ! comp. filesrc \

location=< filename_h265_1080p_30fps.mp4> ! qtdemux ! h265parse !

omxh265dec ! comp. filesrc \

location=< filename_vp8_1080p_30fps.webm> matroskademux ! \

omxvp8dec ! \

comp. filesrc location=<filename_vp9_1080p_30fps.webm> ! \

matroskademux ! omxvp9dec ! comp. -e

INTERPOLATION METHODS FOR VIDEO SCALING

The NVIDIA proprietary nvvidconv Gstreamer-1.0 plugin allows you to choose the

interpolation method used for scaling.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 33

The following table shows the supported values for the nvvidconv

interpolation-method property.

Interpolation Method Property Value

nearest 0

bilinear 1

5-Tap 2

10-Tap 3

smart (default) 4

Nicest 5

Note

Get information on

nvvidconv

interpolation-method

property

with the gst-inspect-1.0

nvvidconv

command.

To use bilinear interpolation method for scaling

 Enter the following command:

gst-launch-1.0 filesrc location=<filename_1080p.mp4>! \

qtdemux name=demux ! h264parse ! omxh264dec ! \

nvvidconv interpolation-method=1 ! \

'video/x-raw(memory:NVMM), format=(string)I420, width=1280, \

height=720' ! nvoverlaysink -e

EGLSTREAM PRODUCER EXAMPLE

The NVIDIA-proprietary nveglstreamsrc and nvvideosink Gstreamer-1.0 plugins allow

simulation of an EGLStream producer pipeline (for preview only.)

To simulate an EGLStream producer pipeline

 Enter the following command:

nvgstcapture-1.0 --camsrc=3

EGL IMAGE TRANSFORM EXAMPLE

The NVIDIA proprietary nvegltransform Gstreamer-1.0 plugin allows simulation of an

EGLImage transform pipeline.

Accelerated Gstreamer User Guide

Accelerated GStreamer User Guide DA_07303-3.9 | 34

To simulate an EGL Image transform pipeline

 Enter the following command:

gst-launch-1.0 filesrc location=<filename_h264_1080p.mp4> ! \

qtdemux ! h264parse ! omxh264dec ! nvvidconv ! \

'video/x-raw(memory:NVMM), width=(int)1280, height=(int)720, \

format=(string)NV12' ! nvegltransform ! nveglglessink -e

Accelerated GStreamer User Guide DA_07303-3.9| 35

GSTREAMER BUILD INSTRUCTIONS

This release contains the gst-install script to install a specific GStreamer version.

This section provides a procedure for building current versions of GStreamer.

To build GStreamer using gst-install

1. Execute the following command:

gst-install [--prefix=<install_path>] [--version=<version>]

Where <install_path> is the location where you are installing GStreamer and

<version> is the GStreamer version. For example:

gst-install --prefix=/home/ubuntu/gst-1.14.4 --version=1.14.4

2. Export environment variables with the following command:

export LD_LIBRARY_PATH=<install_path>/lib/aarch64-linux-gnu

export PATH=<install_path>/bin:$PATH

Where <install_path> is the location where you are installing GStreamer. For

example:

export LD_LIBRARY_PATH=/home/ubuntu/gst-1.14.4/lib/aarch64-linux-gnu

export PATH=/home/ubuntu/gst-1.14.4/bin:$PATH

To build GStreamer manually

1. Download the latest version of gstreamer available at:

http://gstreamer.freedesktop.org/src/

GStreamer Build Instructions

Accelerated GStreamer User Guide DA_07303-3.9 | 36

The following are the files you need from version 1.14.4:

● gstreamer-1.14.4.tar.xz

● gst-plugins-base-1.14.4.tar.xz

● gst-plugins-good-1.14.4.tar.xz

● gst-plugins-bad-1.14.4.tar.xz

● gst-plugins-ugly-1.14.4.tar.xz

2. Install needed packages with the following command:

sudo apt-get install build-essential dpkg-dev flex bison \

autotools-dev automake liborc-dev autopoint libtool \

gtk-doc-tools libgstreamer1.0-dev

3. In the ~/ directory, create a gst_<version> directory, where <version> is the

version number of gstreamer you are building.

4. Copy the downloaded tar.xz files to the gst_<version> directory.

5. Uncompress the tar.xz files in the gst_<version> directory.

6. Set the PKG_CONFIG_PATH with the following command:

export PKG_CONFIG_PATH=/home/ubuntu/gst_1.14.4/out/lib/pkgconfig

7. Build gstreamer (in this example, gstreamer-1.14.4) with the following commands:

./configure --prefix=/home/ubuntu/gst_1.14.4/out

make

make install

8. Build gst-plugins-base-1. 14.4 with the following commands:

sudo apt-get install libxv-dev libasound2-dev libtheora-dev \

libogg-dev libvorbis-dev

./configure --prefix=/home/ubuntu/gst_1.14.4/out

make

make install

9. Build gst-plugins-good-1.14.4 with the following commands:

sudo apt-get install libbz2-dev libv4l-dev libvpx-dev \

libjack-jackd2-dev libsoup2.4-dev libpulse-dev

./configure --prefix=/home/ubuntu/gst_1.14.4/out

make

make install

10. Obtain and build gst-plugins-bad-1.14.4 with the following commands:

GStreamer Build Instructions

Accelerated GStreamer User Guide DA_07303-3.9 | 37

sudo apt-get install faad libfaad-dev libfaac-dev

./configure --prefix=/home/ubuntu/gst_1.14.4/out

make

make install

11. Obtain and build gst-plugins-ugly-1.14.4 with the following commands:

sudo apt-get install libx264-dev libmad0-dev

./configure --prefix=/home/ubuntu/gst_1.14.4/out

make

make install

12. Set the LD_LIBRARY_PATH environment variable with the following command:

export LD_LIBRARY_PATH=/home/ubuntu/gst_1.14.4/out/lib/

13. Copy the nvidia gstreamer-1.0 libraries to the gst_1.14.4 plugin directory

using the following command:

cd /usr/lib/aarch64-linux-gnu/gstreamer-1.0/

cp libgstnv* libgstomx.so \

~/gst_1.14.4/out/lib/gstreamer-1.0/

The nvidia gstreamer-1.0 libraries include:

libgstnvarguscamera.so

libgstnvcompositor.so

libgstnvdrmvideosink.so

libgstnveglglessink.so

libgstnveglstreamsrc.so

libgstnvegltransform.so

libgstnvivafilter.so

libgstnvjpeg.so

libgstnvtee.so

libgstnvvidconv.so

libgstnvvideo4linux2.so

libgstnvvideocuda.so

libgstnvvideosink.so

libgstomx.so

Accelerated GStreamer User Guide DA_07303-3.9| 38

NVGSTCAPTURE-1.0 OPTION REFERENCE

This section describes the options available in the nvgstcapture-1.0 application.

Note:

nvgstcapture-1.0 application default only supports ARGUS API using

nvarguscamerasrc plugin. Legacy nvcamerasrc plugin support is deprecated.

NVGSTCAPTURE APPLICATION OPTIONS

Note:

Use “nvgstcapture-1.0 --help” to list supported options for Nvarguscamera.

Nvgstcapture-1.0 command-line options for nvarguscamera are described in the

following table.

Application Options

Option

Description

Notes

--prev_res

Preview width and height,

Range: 2 to 8 (3840x2160),

e.g., --prev_res=3

--cus-prev-res Custom preview width and

height for CSI only,

e.g., --cus-prev-

res=1920x1080

--image_res

Image width and height,

Range: 2 to 12 (5632x4224),

e.g., --image_res=3

--video-res Video width and height.

Range: 2 to 9 (3896x2192)

e.g., --video-res=3

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303-3.9 | 39

Application Options

Option Description Notes

--camsrc Camera source to use

0=V4L2

1=csi[default]

2=videotest

3=eglstream

-m, --mode Capture mode.

1-Still

2-Video

-v, --video_enc Video encoder type. 0=h264[HW]

1=vp8[HW, not supported on

Jetson AGX Xavier]

2=h265[HW]

3=vp9[HW]

-p, --hw-enc-path Framework Type 0=OMX

1=V4L2

-b, --enc-bitrate Video encoding Bit-rate (in

bytes)

e.g.

--enc-bitrate=4000000

--enc-controlrate Video encoding bit-rate

control method

0 = Disable

1 = variable (Default)

2 = constant

e.g. --enc-controlrate=1

--enc-EnableTwopassCBR Enable two pass CBR while

encoding

0 = Disable

1 = Enable

e.g.

--enc-EnableTwopassCBR=1

--enc-profile

Video encoder profile (only for

H.264)

0-Baseline

1-Main

2-High

-j, --image_enc Image encoder type. 0-jpeg_SW[jpegenc]

1-jpeg_HW[nvjpegenc]

-k, --file_type Container file type.

0-MP4

1-3GP

2-MKV

--file-name Captured file name.

nvcamtest is used by default

--color-format Color format to use 0=I420

1=NV12[For CSI only and

default for CSI]

2=YUY2[For V4L2 only, default

for V4L2]

--orientation Camera sensor orientation

value

--eglConfig

EGL window Coordinates

(x_pos y_pos) in that order

e.g.

--eglConfig="50 100"

-w, --whitebalance Capture whitebalance value. -

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303-3.9 | 40

Application Options

Option Description Notes

--timeout Capture timeout value -

--saturation Camera saturation value. -

--sensor-id Camera Sensor ID value

--display-id [For nvoverlaysink only]

Display ID value

--overlayConfig Overlay Configuration Options

index and coordinates in

(index, x_pos, y_pos, width,

height) order

--overlayConfig="0, 0, 0, 1280,

720"

--cap-dev-node Video capture device node e.g.

--cap-dev-node=0

0=/dev/video0[default],

1=/dev/video1,

2=/dev/video2

--svs

[For USB] (=) chain for video

preview.

[For CSI only] use

“nvoverlaysink"

Help Options

e Description Notes

-h, --help Show help options. -

--help-all Show all help options. -

--help-gst Show Gstreamer options. -

CSI CAMERA SUPPORTED RESOLUTIONS

CSI camera supports the following image resolutions for Nvarguscamera:

 640x480

 1280x720

 1920x1080

 2104x1560

 2592x1944

 2616x1472

 3840x2160

 3896x2192

 4208x3120

 5632x3168

 5632x4224

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303-3.9 | 41

CSI CAMERA RUNTIME COMMANDS

Options for Nvarguscamera

CSI camera runtime commands options for Nvarguscamera are described in the

following table.

Command Description Notes

h Help -

q Quit -

mo:<value> Set capture mode 1-image

2-video

gmo Get capture mode -

so:<val> Set sensor orientation 0-none

1-Rotate counter-clockwise 90

degrees

2-Rotate 180 degrees

3-Rotate clockwise 90 degrees

gso Get sensor orientation -

wb:<value> Set white balance mode 0-off

1-auto

2-incandescent

3-fluorescent

4-warm-fluorescent

5-daylight

6-cloudy-daylight

7-twilight

8-shade

9-manual

gwb Get white balance mode -

st:<value> Set saturation 0-2, e.g., st:1.25

gst Get saturation -

j Capture one image. -

jx<delay> Capture after a delay of

<delay>, e.g., jx5000 to

capture after a 5-second

delay

j:<value> Capture <count> number of

images in succession, e.g., j:6

to capture 6 images.

0 Stop recording video -

1 Start recording video -

2 Video snapshot (while

recording video)

gpcr Get preview resolution -

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303-3.9 | 42

Command

Description

Notes

gicr Get image capture resolution -

gvcr Get video capture resolution -

USB CAMERA RUNTIME COMMANDS

USB Camera Runtime Commands

USB camera runtime commands are described in the following table.

Command

Description

Notes

h Help -

q Quit -

mo:<value> Set capture mode 1-image

2-video

gmo Get capture mode -

j Capture one image. -

jx<delay> Capture after a delay of

<delay>, e.g., jx5000 to

capture after a 5-second

delay

j:<value> Capture <count> number of

images in succession, e.g., j:6

to capture 6 images.

1 Start recording video -

0 Stop recording video -

pcr:<value> Set preview resolution 0-176x144

1-320x240

2-640x480

3-1280x720

gpcr Get preview resolution -

gicr Get image capture resolution -

gvcr Get video capture resolution -

br:<value> Set encoding bit rate (in

bytes)

e.g., br:4000000

gbr Get encoding bit rate -

cdn:<value> Set capture device node

0-/dev/video0

1-/dev/video1

2-/dev/video2

gcdn Get capture device node -

Nvgstcapture-1.0 Option Reference

Accelerated GStreamer User Guide DA_07303-3.9 | 43

Runtime Video Encoder Configuration Options

The following table describes runtime video encoder configuration options supported

for Nvarguscamera.

Command Description Notes

br:<val>

Sets encoding bit-rate (in

bytes)

Example: br:4000000

gbr Gets encoding bit-rate (in

bytes)

ep:<val> Sets encoding profile (for

H.264 only)

Example: ep:1

(0): Baseline

(1): Main

(2): High

gep Gets encoding profile (for

H.264 only)

Enter ’f’ Forces IDR frame on video

encoder (for H.264 only)

NOTES

 The nvgstcapture-1.0 application generates image and video output files in the same

directory as the application itself.

 Filenames for image and video content are in the formats, respectively:

● nvcamtest_<pid>_<sensor_id>_<counter>.jpg

● nvcamtest_<pid>_<sensor_id>_<counter>.mp4

Where:

● <pid> is the process ID.

● <sensor_id> is the sensor ID.

● <counter> is a counter starting from 0 every time you run the application.

Rename or move files between runs to avoid overwriting results you want to save.

 The nvgstcapture-1.0 application supports native capture(video only) mode by

default.

 Advance features, like setting zoom, brightness, exposure, and whitebalance levels,

are not supported for USB camera.

Accelerated GStreamer User Guide DA_07303-3.9| 44

VIDEO ENCODER FEATURES

The Gstreamer-1.0-based gst-omx video encoders support the following features,

respectively:

Video Encoder Feature

H264enc

H265enc

Vp9enc

profile (Baseline / Main / High)  (all)  (Main) 

level   —

bitrate   

peak bitrate   —

stringent bitrate   —

insert-spsppsatidr   

control-rate   

iframeinterval   

qp-range   

temporal-tradeoff   

bit-packetization   

preset-level   

low-latency   

slice-header spacing   —

force-IDR   

vbv-size   

sliceintrarefreshenable   —

sliceintrarefreshinterval   —

EnableTwoPassCBR   

num-B-Frames  — —

Video Encoder Features

Accelerated GStreamer User Guide DA_07303-3.9 | 45

The Gstreamer-1.0-based gst-v4l2 video encoders support the following features,

respectively :

Video Encoder Feature H264enc H265enc Vp9enc

profile (Baseline / Main / High)  (all)  (Main) 

control-rate   

bitrate   

insert-spsppsatidr  — —

profile  — —

quantization range for I, P and

B frame

  —

iframeinterval   

qp-range   —

bit-packetization   —

preset-level   

slice-header spacing   —

force-IDR   

EnableTwoPassCBR   —

Enable cabac-entropy-coding  — —

Enable MVBufferMeta   —

Insert aud   —

Insert vui   —

num-B-Frames  — —

Accelerated GStreamer User Guide DA_07303-3.9| 46

SUPPORTED CAMERAS

This section describes the supported cameras.

CSI CAMERAS

 Jetson AGX Xavier can capture images from RAW Bayer sensors. Multiple sensors

can be connected via the CSI interface. However, the current software version is

validated to capture images from one sensor at a time.

 The platform is validated to capture images and video from the OV5693 sensor and

IMX274 sensor module on L4T.

 The current software version is not validated to capture in HDR (High Dynamic

Range) mode.

 The camera module is interfaced with the Tegra platform via MIPI-CSI.

 Tested using the nvgstcapture application.

USB 2.0 CAMERAS

The following camera has been validated on Tegra platforms for Android and L4T with

USB 2.0 ports. This camera is UVC compliant.

 Logitech c920 (preferred)

http://www.logitech.com/en-in/product/hd-pro-webcam-c920

INDUSTRIAL CAMERA DETAILS

The following USB 3.0 Industrial camera is validated on Jetson AGX Xavier under L4T:

 See3CAM_CU130

http://www.e-consystems.com/UltraHD-USB-Camera.asp

Supported Cameras

Accelerated GStreamer User Guide DA_07303-3.9 | 47

●

USB 3.0

● UVC compliant

● 3840 x 2160 at 30 FPS | 4224 x 3156 at 13 FPS

● Purpose - Embedded Navigation

● Test using the nvgstcapture app.

● Issues encountered:

― FPS cannot be fixed. Changes based on exposure.

― FPS cannot be changed. Needs payment to vendor to get the support added

to their firmware.

www.nvidia.com

Notice

ALL NVIDIA DESIGN SPECIFICATIONS, REFERENCE BOARDS, FILES, DRAWINGS, DIAGNOSTICS, LISTS, AND OTHER

DOCUMENTS (TOGETHER AND SEPARATELY, "MATERIALS") ARE BEING PROVIDED "AS IS." NVIDIA MAKES NO

WARRANTIES, EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE WITH RESPECT TO THE MATERIALS, AND ALL

EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY

OR CONDITION OF TITLE, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE

AND NON-INFRINGEMENT, ARE HEREBY EXCLUDED TO THE MAXIMUM EXTENT PERMITTED BY LAW.

Information furnished is believed to be accurate and reliable. However, NVIDIA Corporation assumes no

responsibility for the consequences of use of such information or for any infringement of patents or other rights

of third parties that may result from its use. No license is granted by implication or otherwise under any patent

or patent rights of NVIDIA Corporation. Specifications mentioned in this publication are subject to change

without notice. This publication supersedes and replaces all information previously supplied. NVIDIA

Corporation products are not authorized for use as critical components in life support devices or systems

without express written approval of NVIDIA Corporation.

Trademarks

NVIDIA, the NVIDIA logo, CUDA, Jetson, and Tegra are trademarks or registered trademarks of NVIDIA

Corporation in the United States and other countries. Other company and product names may be trademarks

of the respective companies with which they are associated.
